T Series Core Network Router

T1600

Part Number Description

Control Board for T-Series LCC, use with TX Matrix Plus, Base Bundle

Control Board for T-Series LCC, use with TX Matrix Plus, Redundant

Control Board for T-Series LCC, use with TX Matrix Plus, Spare

T-Series Control Board for Standalone and Multichassis Systems (this is required for multichassis operations)

T-Series Control Board for Stanalone and Multichassis Systems (redundant)

AC Power Cord, Straight, Delta

AC Power Cord, Straight, Wye

Chassis with Backplane installed

T640 Line Card Chassis Connector Interface Panel Spare

T1600 Craft Display Panel

T-Series Rear Fan Tray Base Bundle

Rear Fan Tray for T640 or T1600, Base Bundle

(1) 8 fan, fan tray for T640 or TX Matrix - Spare

Rear Fan Tray for T-Series chassis configured as T4000 or as a TXP LCC, Base Bundle

Rear Fan Tray for T-Series chassis configured as T4000 or as a TXP LCC, Spare

Quiet Fan Tray Bottom Base Bundle

Quiet Fan Tray Top Base Bundle

T-Series Fantray Base Bundle

T640 Fan Tray Spare

T640 Filter Kit (includes Front, Rear, and PEM Air Filters), used on T640, T1600, TX Matrix

T640 Shipping Container Spare

AC Power Supply, Delta with cable for T1600 base bundle

AC Power Supply, Delta, spare with cable

AC Power Supply, Wye with cable for T1600 base bundle

AC Power Supply, Wye, spare with cable

Kit Rear and side air filter for PWR-T-6-60-DC

Bus bar for bridging two inputs posts on PWR-T-6-60-DC, 6 pieces

3 X 80 Amp Power Entry module for T1600 base bundle

3 X 80 Amp Power Entry module for T1600 Spare

Power entry module 4 X 60A DC Base Bundle

Power entry module 4 X 60A DC Spare

Routing engine with dual core 1800MHz processor, SSD and 16GB memory, Base Bundle

Routing engine with dual core 1800MHz processor, SSD and 16GB memory, Redundant

Routing engine with dual core 1800MHz processor, SSD and 16GB memory, Spare

Routing engine with dual core 1800MHz processor, SSD and 16GB memory, Worldwide, Spare

Routing engine with dual core 1800MHz processor, SSD and 8GB memory, Base Bundle

Routing engine with dual core 1800MHz processor, SSD and 8GB memory, Redundant

Routing engine with dual core 1800MHz processor, SSD and 8GB memory, Spare

Routing engine with dual core 1800MHz processor, SSD and 8GB memory, Spare

T-Series Sonet Clock Generator Board redundant option

T640 Sonet Clock Generator Board (included in T640BASE-DCprice)

T-Series Sonet Clock Generator supporting external clocking, Base Bundle

T-Series Sonet Clock Generator supporting external clocking, Redundant

T-Series Sonet Clock Generator supporting external clocking, Spare

Switched Interface board for T1600 100G

Switched Interface board for T1600 100G

Switch Interface Board for LCC connection to TX Matrix Plus

Switch Interface Board for LCC connection to TX Matrix Plus, Spare

T640 to T1600 upgrade kit with two 3 X80 Amp Power Enrry Modules, five SIB-I-T1600 switch interface boards, and 1 CRAFT-T1600-S Craft Panel

T640 to T1600 upgrade kit with (5) SIB-I-T1600, (2) PWR-T1600-3-80-DC-S + (1) CRAFT-T1600-S + (1) PD-1CE-CFP-FPC4. Optics sold separately.

T640 to T1600 upgrade kit with (5) SIB-I-T1600, (2) PWR-T1600-3-80-DC-S + (1) CRAFT-T1600-S + (1) T1600-FPC4-ES + (1) PD-4XGE-XFP. Optics sold separately

T640 to T1600 upgrade kit with (5) SIB-I-T1600, (2) PWR-T1600-3-80-DC-S + (1) CRAFT-T1600-S + (1) T1600-FPC4-ES + (1) PD-5-10XGE-SFPP. Optics sold separately.

T1600 line card chassis 8 slots with cooling system, Backplane, 1 Routing engine, 1 Control Board, 1 Sonet clock Generator, 1 CIP and 2 power entry modules.

Bundle: Contains (1) T1600BASE unit, (5) SIB-I-T1600, (2) SCG-T-BB, (1) FAN-REAR-TX-T640-BB. PEMs, (2) RE-DUO-C1800-8G-BB, and (2) CB-LCC-BB must be selected in the configurator, but are included in the bundle price.

Bundle: Contains (1) T1600BASE unit, (5) SIB-TXP-T1600, (1) FAN-REAR-TXP-LCC-BB, (2) SCG-T-BB, (2) CB-LCC-BB, (2) RE-DUO-C1800-8G-BB. PEMs must be selected in the configurator, but are included in the bundle price.

Upgrade kit including T4000-FPC5-3D and PF-12XGE-SFPP, as well as 2 RE-DUO-C1800-8G, 2 CB-LCC, 5 SIB-I-T4000, 1 FAN-REAR-TXP-LCC-S, 2 FANTRAY-T4000-S, 1 CRAFT-T-SERIES-S, and 2 PWR-T-6-60-DC.

Upgrade kit including T4000-FPC5-3D and PF-1CGE-CFP, as well as 2 RE-DUO-C1800-8G, 2 CB-LCC, 5 SIB-I-T4000, 1 FAN-REAR-TXP-LCC-S, 2 FANTRAY-T4000-S, 1 CRAFT-T-SERIES-S,and 2 PWR-T-6-60-DC.

Upgrade kit including T4000-FPC5-3D and PF-24XGE-SFPP, as well as 2 RE-DUO-C1800-8G, 2 CB-LCC, 5 SIB-I-T4000, 1 FAN-REAR-TXP-LCC-S, 2 FANTRAY-T4000-S, 1 CRAFT-T-SERIES-S, and 2 PWR-T-6-60-DC.

Upgrade kit including 2 RE-DUO-C1800-8G, 2 CB-LCC, 5 SIB-I-T4000, 1 FAN-REAR-TXP-LCC-S, 2 FANTRAY-T4000-S, 1 CRAFT-T-SERIES-S, and 2 PWR-T-6-60-DC.

T640/T1600 upgrade kit, contains qty 2 CB-LCC-S and qty 5 SIB-TXP-T1600 ( order RE's separately)

T320

Part Number Description

T-Series Control Board for Stanalone and Multichassis Systems (spare)

T320 Chassis with Installed Backplane Spare

T320 Connector Interface Panel Spare

T320 Craft Interface Panel Spare

T320 Fan Tray Spare

T320 Filter Kit (includes Front, Rear, and PEM Air Filters),

T320 Shipping Container Spare

T320 DC Power Entry Module Spare

T320 Blower Rear Right Spare

T-Series Sonet Clock Generator Board redundant option

T320 Sonet Clock Generator Board (included in T320BASE-DC price)

T320 SONET Clock Generator Spare

T320 Switch Interface Board (3 required per T320 Base System)

T320 Switch Interface Board Spare

T320 Line Card Chassis: 8 slot chassis with cooling system, Backplane, 1 Routing Engine, 1 Control Board, 1 SONET Clock Generator, 1 CIP, and 2 DC Power Entry Modules

T4000

Part Number Description

Chassis with back plane installed

T Series Craft Display Panel

Front Fan Tray, Base Bundle

Front Fan Tray, Spare

Power entry module 6 X 60A DC Base Bundle

Power entry module 6 X 60A DC, Spare

Switched Interface board for T4000

Switched Interface board for T4000, Spare

T4000 standalone chassis 8 slots with cooling system, Backplane, 1 Routing engine, 1 Control Board, 1 Sonet clock Generator, 1 CIP and 2 power entry modules.

T4000 Base System pre-configured with redundnat common equipment: (1)T4000BASE, (2)FANTRAY-T4000-BB, (1)FAN-REAR-TXP-LCC-BB, (2)RE-DUO-C1800-8G-BB, (2)CB-LCC-BB, (2)SCG-T-EC-BB, (2)PWR-T-6-60-DC-BB, (5)SIB-I-T4000.

T640

Part Number Description

T640 Chassis with Installed Backplane

T640 Craft Interface Panel Spare

T-Series Rear Fan Tray Spare

Quiet Fan Tray Bottom Spare

Quiet Fan Tray Top Spare

T-Series Quiet Fan Tray Kit

T640 Sonet Clock Generator Board Spare

T640 Switch Interface Board (5 required per T640 Base System)

T640 Switch Interface Board, Version B (5 required per T640 Base System)

T640 Switch Interface Board, Version B, Spare

T640 Switch Interface Board Spare

(1) multichassis Switch Interface Board

(1) multichassis Switch Interface Board, Spare

T640 line card chassis 8 slots with cooling system, Backplane, 1 Routing engine, 1 Control Board, 1 Sonet clock Generator, 1 CIP and 2 power entry modules.

A bundled kit to migrate an existing T640, containing (5) SIB-TX-T640-S, (2) CB-T-S and (1) FAN-REAR-TX-T640-S

TX Matrix

Part Number Description

(1) Control Board for TX Matrix - Base Bundle

(1) Control Board for TX Matrix - Redundant

(1) multi chassis Control Board- Spare

(1) Cable shelf for telco rack - Spare

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 100 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 10 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 12 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 15 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 20 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 25 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 30 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 35 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 40 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 45 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 4 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 50 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 55 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 5 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 60 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 65 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 6 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 70 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 75 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 80 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 85 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 90 meters

(1) fiber array cable to interconnect SIB-4-TX to SIB-TX-T640, 95 meters

(1) TX Matrix chassis and backplane spare (no CB, CIP or SIBs)

(1) Connector Interface Panel for TX Matrix - Spare

(1) Craft panel for TX Matrix - Spare

(1) Front fan tray - Spare

(1) Shipping packaging for TX Matrix-Spare

(1) Switch Interface Board for TX Matrix

(1) Switch Interface Board for TX Matrix - Spare

TX Matrix Shelf Bundle, includes:(1) 19inch 5 front facing slots Shelf, (1) Route Engine (RE-1600-2048), (1) Control Board, (2) Connector Interface Panel, (2) DC Power Entry Modules, requires JUNOS 7.0 or greater

TX Matrix Plus

Part Number Description

Control Board for TX Matrix Plus, Base Bundle

Control Board for TX Matrix Plus, Spare

Cable manger assembly for rear trunk fibers. Attaches to the LCCs that are part of to a TX Matrix Plus routing node.

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 4 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 6 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 8 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 10 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 12 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 15 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 20 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 25 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 30 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 35 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 40 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 45 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 50 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 55 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 60 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 65 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 70 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 75 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 80 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 85 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 90 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 95 meters

(1) fiber array cable to interconnect SIB-TXP-T1600 to SIB-TXP-F13, 100 meters

Compact Flash, 4G for RE, Spare

TX Matrix Plus Chassis with Installed Backplane, Spare

Connector Interface Panel for TX Matrix Plus, Base Bundle

Craft Interface Panel for TX Matrix Plus, Spare

Front Display Panel for TX Matrix Plus, Spare

Front Fan Tray for TX Matrix Plus, Spare

Rear Fan Tray for TX Matrix Plus, Spare

(1) Air Filter for TX Matrix Plus, Horizontal, Spare

(2) Air Filters for TX Matrix Plus, Vertical, Spare

Loopback Plug for TX Matrix Plus bulkhead, Spare

Loopback Plug for TX Matrix Plus cable end adapter, Spare

(1) Shipping packaging for TX Matrix Plus, Spare

Slide Out Tray for Power Connections, TX Matrix Plus PEM, Spare

7 x 60 Amp DC Power Entry module for TX Matrix Plus, Spare

Routing engine with dual core 2600MHz processor, SSD and 16GB memory, Base Bundle

Routing engine with dual core 2600MHz processor, SSD and 16GB memory, Redundant

Routing engine with dual core 2600MHz processor, SSD and 16GB memory, Spare

Routing engine with dual core 2600MHz processor, SSD and 16GB memory, Spare

Switch Interface Board for TX Matrix Plus, fabric stages one and three

Switch Interface Board for TX Matrix Plus, fabric stages one and three, Spare

Switch Interface Board for TX Matrix Plus, fabric stage two

Switch Interface Board for TX Matrix Plus, fabric stage two, Spare

Solid State Drive, 64G for RE, Spare

Blank plate for TX Matrix Plus fabric stage one, three slot, Spare

TX Matrix Plus installation toolkit includes loopbacks and fiber cleaning supplies

TX Matrix Plus Base Chassis fully redundant, includes 2 Res, 2 CBs, 2 CIPs

USB Memory, 4G for RE, Spare
